Automatic round bottle labeling and sticker applicator EZlabe RL550
EZlabel RL550 is a high-performance Automatic Round-Bottle Labeling Machine developed specifically for round workpieces such as water bottles, sauce bottles, tubes and medicine bottles. It supports inline single- and double-side labeling, is controlled by a precise PLC system, and delivers up to 20-60 pcs/min. Ideal for food, beverage, cosmetics and chemical industries.
Applicable Products
● Round containers: e.g. plastic bottles, glass bottles, cans
with a diameter up to 140 mm (customizable to your workpiece)
Key Features of the EZlabel RL550
- ●Easy to use: Controlled by PLC and Touch Screen with an intuitive menu — no specialist operator required.
- ●Durable build: Made of stainless steel SUS304 and anodized aluminum alloy — strong, corrosion-resistant and rust-free.
- ●Precise positioning: Label feeding driven by a Stepping Motor with a high-stability label sensor to reduce misapplication.
- ●Date printing ready: A production/expiry date printer can be mounted on the machine (Production Date Printer / Print and Apply Labeler).
- ●Highly flexible: Easy label position adjustment, supports inline production lines, and moves easily on casters.
Technical Specifications
| Specification | Detail |
|---|---|
| Labeling speed | Approx. 20-60 pcs/min (depending on workpiece shape) |
| Labeling accuracy | +/- 1-2 mm |
| Workpiece size | Capsule & Bottle, diameter up to 140 mm (adjustable to design) |
| Label dispensing speed | Up to 5-20 m/min |
| Label size | Height: 10-140 mm | Length: 15-300 mm |
| Label roll | 3-inch core, OD up to 300 mm, length 300 m, face out |
| Label feed direction | Left to right |
| Power supply | AC 220V 50/60Hz 90W |
| Dimensions & weight | 2100 * 900 * 1550 mm | 250 kg |
Order / Request a Quote / Machine Demo
Line Official Account: @kimac
Office: +66-2-956-8291-2
Sales: +66-80-854-4137 or +66-84-088-5158
Applicable Products
● Round shapes such as plastic bottles, glass bottles, and various cans
With product diameter not exceeding 140 mm (customizable based on product size)
Specifications
